技術參數

◎規格：端鈕盒銅條，小A(7×9)、中A(9×11、10×12)、

    大A(11×13)

◎電流配置：三相四線1.5(6)A帶10個輔助端口

                      三相四線10(40)A帶10個輔助端口

                      三相四線20(100)A帶10個輔助端口

                      另有三相三線小電流端口可選配

◎說明：采用拆分式端鈕盒設計，經濟實惠。

TECHNICAL PARAMETERS

◎Specifications: copper bar of terminal box, small A(7×9), middle A

    (9×11, 10×12), large A(11×13)

◎Current configuration: three-phase four-wire 1.5(6)A with 10 auxiliary ports

                          three-phase four-wire 10(40)A with 10 auxiliary ports

                          three-phase tour-wire 20(100)A with 10 auxiliary ports

                          three-phase three-wire with low current port is optional

◎Note: it uses split terminal box which is convenient and affordable.
